Flat Sheet-200
The NPC-F-120 Flat Sheet Ceramic Membrane, developed by Nano Palayesh Ceram (NPC), is a plate-type ceramic membrane designed for vacuum-driven and low-pressure filtration processes. Installed in frame modules, the flat sheet structure allows filtrate to be drawn perpendicularly, typically operating in an outside-in flow configuration.
Manufactured from high-performance ceramic materials such as Zirconia, Alumina, and Silicon Carbide, this membrane offers excellent chemical, thermal, and mechanical stability. Its design supports dead-end and submerged filtration setups, making it suitable for industrial applications requiring reliable performance, easy maintenance, and long service life.
- Plate-type flat sheet ceramic membrane structure
- Outside-in flow configuration
- High filtration area in a compact flat sheet design
- Designed for low-pressure or vacuum-driven filtration
- Ceramic support materials: Zirconia (ZrO₂), Alumina (Al₂O₃), Silicon Carbide (SiC)
- Microfiltration (MF), Ultrafiltration (UF) and Nanofiltration (NF) separation layers
- Suitable for dead-end, cross-flow, and submerged MBR configurations
- Easy integration into modular racks or custom housings
- Compatible with CIP and backflush protocols
- Model Code: NPC-F-200
- Membrane Type: Flat Sheet Ceramic
- Total Width: 200 mm
- Channel Width: 3 mm
- Thickness: 11 mm
- Length: 1000 mm
- Filtration Surface Area: ~0.422 m²
- Filtration Mode: Dead-end (typically vacuum-driven)
- Operating Pressure: 0.1 – 0.8 bar
- Operating Temperature: 5 – 80 °C
- pH Range: 0 – 14 (material/module-dependent)
- Porosity: 45 ± 5%
- Separation Layer Options:
- Microfiltration (MF): 200 nm
- Ultrafiltration (UF): 50 nm, 100 nm
- Typical Pure Water Permeability (SiC, 25°C, vacuum operation):
- ~5,000 LMH/bar (100 nm)
- ~6,000–7,000 LMH/bar ( 200 nm)
- Food & Beverage: Clarification, microbial control, protein recovery
- Pharmaceutical & Biotech: Cell broth filtration, enzyme and protein separation
- Petrochemical: Oil–water separation, catalyst recovery
- Water Treatment: MBR polishing, RO pretreatment
The NPC-F-200 flat sheet ceramic membrane offers a high filtration area in a compact design, suitable for low-pressure or vacuum-driven applications. Its ceramic construction ensures excellent chemical and thermal resistance, while compatibility with dead-end, cross-flow, and submerged MBR setups allows flexible installation. Smooth surfaces minimize fouling and support efficient CIP and backflush protocols, making maintenance easy and extending membrane lifespan. Modular design allows seamless integration into racks or custom housings.
